MF Mineral Fiber

The bass is the foundation of all music and this line has been design with this goal in mind: to provide you the best sensations of the lowest frequencies. If you want to feel the Music, MF is the best choice, the Mineral Fiber cone provides a great impact and a low extension for a realistic listening experience of the lower end of the frequencies.

MF LINE

MF 6.1 Coax
Two Way Coaxial System
1" Soft Dome Neodymium Tweeter
6.5" Mineral Fiber Cone Mid/Bass Driver with High-Tight Fiber Basket
Power Handling RMS/MAX:
70/140 Watts
Sensitivity (SPL@1W):
90dB
Frequency Response:
45Hz - 20Khz
Two Way Systems
MF 4.1 Kit
Two Way System with two 1.1 Tweeters, two crossovers and two MF 4.1 Mid/Basses
1" Silk Dome Neodymium Tweeter
4" Mineral Fiber Cone Mid/Bass Driver with High-Tight Fiber Basket
12dB Two Way Passive Crossover
Power Handling RMS/MAX:
50/100 Watts
Sensitivity (SPL@1W):
89dB
Frequency Response:
55Hz - 20Khz
MF 5.1 Kit
Two Way System with two 1.1 Tweeters, two crossovers and two MF 5.1 Mid/Basses
1" Silk Dome Neodymium Tweeter
5.25" Mineral Fiber Cone Mid/Bass Driver with High-Tight Fiber Basket
12dB Two Way Passive Crossover
Power Handling RMS/MAX:
60/120 Watts
Sensitivity (SPL@1W):
89dB
Frequency Response:
45Hz - 20Khz
MF 6.1 Kit
Two Way System with two 1.1 Tweeters, two crossovers and two MF 6.1 Mid/Basses
1" Silk Dome Neodymium Tweeter
6.5" Mineral Fiber Cone Mid/Bass Driver with High-Tight Fiber Basket
12dB Two Way Passive Crossover
Power Handling RMS/MAX:
70/140 Watts
Sensitivity (SPL@1W):
90dB
Frequency Response:
40Hz - 20Khz
Three Way Systems
MF 6.3 Kit
Three Way System with two 1.1 Tweeters, two crossovers, two MF 3.1 Midranges and two MF 6.1 Mid/Basses
1" Silk Dome Neodymium Tweeter
3" Cellulose Fiber Cone Midrange Driver with High-Tight Fiber Basket
6.5" Cellulose Fiber Cone Mid/Bass Driver with High-Tight Fiber Basket
12dB Two Way Passive Crossover
Power Handling RMS/MAX:
80/160 Watts
Sensitivity (SPL@1W):
89dB
Frequency Response:
40Hz - 20Khz
Tweteers
1.1
1" Silk Dome Neodymium Tweeter
Power Handling RMS/MAX:
15/50 Watts
Sensitivity (SPL@1W):
91dB
Frequency Response:
2.5Khz - 20Khz
Midranges
MF 3.1 Midrange

Power Handling RMS/MAX:
30/80 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
0.3Khz - 5.5Khz
Mid/Basses
MF 4.1 Mid/Bass
Power Handling RMS/MAX:
50/100 Watts
Sensitivity (SPL@1W):
91dB
Frequency Response From:
55hz
MF 5.1 Mid/Bass
Power Handling RMS/MAX:
60/120 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response From: 45hz
MF 6.1 Mid/Bass
Power Handling RMS/MAX:
80/160 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response From: 40hz
