Unique solutions with a no compromise sound quality. This could be the definition that describes better than any other the Studio Line, which represents the latest applications of new technologies, materials and engineering in the audio industry.
This is not only the ultimate expression of PHD Audiophile Sound Systems, but also a benchmark for the competitors.

Studio Line

Two Way Systems
Studio 4.1 Kit
Two Way System with two 1.Silk Tweeters, two crossovers and two 4.1 Studio Mid/Basses

Features


1" Silk Dome Neodymium Tweeter
4" Fiberglass/Kevlar Cone Mid/Bass Driver with High-Tight Fiber Basket
12dB Two Way Passive Crossover
Power Handling RMS/MAX:
80/160 Watts
Sensitivity (SPL@1W):
89dB
Frequency Response:
50Hz - 20Khz
Studio 6.1 Kit
Two Way System with two 1.Silk Tweeters, two crossovers and two 6.1 Studio Mid/Basses

Features
1" Silk Dome Neodymium Tweeter
6,5" Fiberglass/Kevlar Cone Mid/Bass Driver with High-Tight Fiber Basket
12dB Two Way Passive Crossover
Power Handling RMS/MAX:
100/200 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
40Hz - 20Khz
Two Way Competition Systems
Studio 4.1 Kit C
Two Way System with two 1.C Tweeters, two Crossovers and two 4.1 Studio Mid/Basses

Features

1" Silk Dome Neodymium Tweeter with CNC Aluminum Case and Rear Chamber
4" Fiberglass/Kevlar Cone Mid/Bass Driver with High-Tight Fiber Basket
12dB Two Way Passive Crossover
Power Handling RMS/MAX:
80/160 Watts
Sensitivity (SPL@1W):
89dB
Frequency Response:
50Hz - 20Khz


Studio 6.1 Kit C
Two Way System with two 1.C Tweeters, two Crossovers and two 6.1 Studio Mid/Basses

Features

1" Silk Dome Neodymium Tweeter with CNC Aluminum Case and Rear Chamber
6,5" Fiberglass/Kevlar Cone Mid/Bass Driver with High-Tight Fiber Basket
12dB Two Way Passive Crossover
Power Handling RMS/MAX:
100/200 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
40Hz - 20Khz

Three Way Systems
Studio 6.2 Kit
Three Way System with two 1.Silk Tweeters, two Crossovers, two 2.5" Studio WMT Full range drivers and two 6.1 Studio Mid/Basses


Features
1" Silk Dome Neodymium Tweeter
2.5" WMT Full Range Driver with High-Tight Fiber Basket
6,5" Fiberglass/Kevlar Cone Mid/Bass Driver with High-Tight Fiber Basket
12dB Three Way Passive Crossover;
Power Handling RMS/MAX:
120/240 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
35Hz - 20Khz

Studio 6.3 Kit
Three Way System with two 1.Silk Tweeters, two Crossovers, two 3.1 Studio Midranges and two 6.1 Studio Mid/Basses

Features
1" Silk Dome Neodymium Tweeter
3" Fiberglass/Kevlar Cone Midrange Driver with High-Tight Fiber Basket
6,5" Fiberglass/Kevlar Cone Mid/Bass Driver with High-Tight Fiber Basket
12dB Three Way Passive Crossover;
Power Handling RMS/MAX:
120/240 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
35Hz - 20Khz
Three Way Competition Systems
Studio 6.2 Kit C
Three Way System with two 1.C Tweeters, two Crossovers, two 2.5" Studio WMT Full range drivers and two 4.1 Studio Mid/Basses

Features
1" Silk Dome Neodymium Tweeter with CNC Aluminum Case and Rear Chamber
2.5" WMT Full Range Driver with High-Tight Fiber Basket
6,5" Fiberglass/Kevlar Cone Mid/Bass Driver with High-Tight Fiber Basket
12dB Three Way Passive Crossover;
Power Handling RMS/MAX:
120/240 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
35Hz - 20Khz

Studio 6.3 Kit C
Three Way System with two 1.C Tweeters, two Crossovers, two 3.1 Studio Midranges , and two 6.1 Studio Mid/Basses

Features
1" Silk Dome Neodymium Tweeter with CNC Aluminum Case and Rear Chamber
3" Fiberglass/Kevlar Cone Midrange Driver with High-Tight Fiber Basket
6,5" Fiberglass/Kevlar Cone Mid/Bass Driver with High-Tight Fiber Basket
12dB Three Way Passive Crossover;
Power Handling RMS/MAX:
120/240 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
35Hz - 20Khz
Studio Pro - Two Way Systems
Studio 4.1 Kit PRO
Two Way System with two 1.C Tweeters, two Crossovers and two 4.1 Studio PRO Mid/Basses

Features

1" Silk Dome Neodymium Tweeter with CNC Aluminum Case and Rear Chamber
4" Fiberglass/Kevlar Cone Mid/Bass Driver with CNC Aluminum Basket
12dB Two Way Passive Crossover
Power Handling RMS/MAX:
80/160 Watts
Sensitivity (SPL@1W):
89dB
Frequency Response:
45Hz - 20Khz

Studio 6.1 Kit PRO
Two Way System with two 1.C Tweeters, two Crossovers and two 6.1 Studio PRO Mid/Basses

Features
1" Silk Dome Neodymium Tweeter with CNC Aluminum Case and Rear Chamber
6,5" Fiberglass/Kevlar Cone Mid/Bass Driver with CNC Aluminum Basket
12dB Two Way Passive Crossover
Power Handling RMS/MAX:
100/200 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
35Hz - 20Khz
Studio Pro - Three Way Systems
Studio 6.3 Kit PRO
Three Way System with two 1.C Tweeters, two Crossovers, two 3.1 Studio PRO Midranges, and two 6.1 Studio PRO Mid/Basses

Features
1" Silk Dome Neodymium Tweeter with CNC Aluminum Case and Rear Chamber
3" Fiberglass/Kevlar Cone Mid/Bass Driver with CNC Aluminum Basket
6,5" Fiberglass/Kevlar Cone Mid/Bass Driver with CNC Aluminum Basket
12dB Three Way Passive Crossover;
Power Handling RMS/MAX:
120/240 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
35Hz - 20Khz
6.4 Studio Kit PRO
Three Way System with two 1.C Tweeters, two Crossovers, two 4" Studio PRO Mid/Basses, and two 6.1 Studio PRO Mid/Basses

Features
1" Silk Dome Neodymium Tweeter with CNC Aluminum Case and Rear Chamber
4" Fiberglass/Kevlar Cone Mid/Bass Driver with CNC Aluminum Basket
6,5" Fiberglass/Kevlar Cone Mid/Bass Driver with CNC Aluminum Basket
12dB Three Way Passive Crossover
Power Handling RMS/MAX:
120/240 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
35Hz - 20Khz
Tweeters
1.Silk Tweeter
1" Silk Dome Neodymium Tweeter
Power Handling RMS/MAX:
15/50 Watts
Sensitivity (SPL@1W):
91dB
Frequency Response:
2Khz - 20Khz

1.C Tweeter
1" Silk Dome Neodymium Tweeter with CNC Aluminum Case and Rear Chamber
Power Handling RMS/MAX:
30/60 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
1.5Khz - 20Khz
Mini Studio Tweeter
1" Silk Dome Neodymium Tweeter with CNC Aluminum Case and Rear Chamber
Power Handling RMS/MAX:
30/80 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
1.0Khz - 20Khz
1.Studio Tweeter
1" Silk Dome Neodymium Tweeter with CNC Aluminum Case and Rear Chamber
Power Handling RMS/MAX:
30/80 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
0.8Khz - 20Khz
Midranges
Studio 2.5" WMT
Power Handling RMS/MAX:
30/80 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
0.2Khz - 20Khz
Studio 3.1 Midrange
Power Handling RMS/MAX:
30/80 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response:
0.3Khz - 5.5Khz
Studio PRO 3.1 Midrange
Power Handling RMS/MAX:
30/80 Watts
Sensitivity (SPL@1W):
91dB
Frequency Response:
0.2Khz - 7.5Khz
Mid/Basses
Studio 4.1 Mid/Bass
Power Handling RMS/MAX:
30/80 Watts
Sensitivity (SPL@1W):
91dB
Frequency Response From:
50hz
Studio 6.1 Mid/Bass
Power Handling RMS/MAX:
30/80 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response From: 40hz
Studio 6.2 NEO/Ferrite Magnets Mid/Bass
Power Handling RMS/MAX:
30/80 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response From:
35hz
Studio PRO 4.1 Mid/Bass
Power Handling RMS/MAX:
30/80 Watts
Sensitivity (SPL@1W):
91dB
Frequency Response From:
45hz
Studio PRO 6.1 Mid/Bass
Power Handling RMS/MAX:
30/80 Watts
Sensitivity (SPL@1W):
92dB
Frequency Response From:
35hz
